View full size image

Caption:

Norfolk, Va. (June 30, 2006) -- Artist Rendering - Cutaway illustration of the U.S. Navy's San Antonio-class amphibious transport dock ship (LPD).  The amphibious transports are used to transport, and land Marines, their equipment and supplies by embarked air cushion or conventional landing craft or amphibious vehicles, augmented by helicopters or vertical take off and landing aircraft in amphibious assault, special operations, or expeditionary warfare missions. Illustration provided courtesy Naval Sea Systems Command (RELEASED)

More detailed information for US Military equipment and procedures is available in the Data Store


US Military Equipment Technical Manuals | US Army Field Manuals | Marine Corps Warfighting Manuals | US Navy Non-Resident Training Course (NRTC) Manuals | 3D Military Computer Models

Photo description

Photo Date
June 30, 2006
Photographer
NAVSEA
Caption Writer
Christopher Madden, Director, NVNS
Copyright Status
Public domain / free use
Service Branch
US Navy
Primary Equipment
LPD 17
Other Visible Equipment
Not available
Plane Number
Not available
Base
Not available
Tail Code
Not available
Squadron
Not available
Comments/Notes
3D rendering
