CLASS SPECIFIC INFORMATION
KITTY
HAWK Class Specifications
|
Overall Length
|
1069'
- 0" |
Waterline Length
|
990'
- 0" |
Extreme Beam
|
282'
- 0" |
Waterline Beam
|
130'
- 0" |
Max. Navigational Draft
|
38'
- 0" |
Draft, Keel
|
Not
available |
Draft Limit
|
38'
- 0" |
Light Displacement
|
60,933
tons |
Full Displacement
|
81,780
tons |
Structural Composition
|
Hull:
Steel; Superstructure: Steel |
Number of Propellers
|
4 |
Propulsion Type
|
Steam
Turbine; (4) |
Total Shaft Horsepower
|
280,000
shp |
Speed
|
30+
knots |
Crew (typ.)
|
Officers:
578; Enlisted: 5046 |
|
|
ENTERPRISE Class
Specifications
|
Overall Length
|
1088'
- 0" |
Waterline Length
|
1040'
- 0" |
Extreme Beam
|
248'
- 0" |
Waterline Beam
|
133'
- 0" |
Max. Navigational Draft
|
39'
- 0" |
Draft, Keel
|
Not
available |
Draft Limit
|
39'
- 0" |
Light Displacement
|
75,704
tons |
Full Displacement
|
93,284
tons |
Structural Composition
|
Hull:
Steel; Superstructure: Steel |
Number of Propellers
|
4 |
Propulsion Type
|
(8)
Westinghouse A2W Nuclear Reactors powering (4) Steam
Turbines |
Total Shaft Horsepower
|
280,000
shp |
Speed
|
30+
knots |
Crew (typ.)
|
Officers:
540; Enlisted: 4818 |
|
|
JOHN
F. KENNEDY Class Specifications
|
Overall Length
|
1059'
- 0" |
Waterline Length
|
990'
- 0" |
Extreme Beam
|
252'
- 0" |
Waterline Beam
|
130'
- 0" |
Max. Navigational Draft
|
36'
- 0" |
Draft, Keel
|
Not
available |
Draft Limit
|
37'
- 0" |
Light Displacement
|
60,728
tons |
Full Displacement
|
82,655
tons |
Structural Composition
|
Hull:
Steel; Superstructure: Steel |
Number of Propellers
|
4 |
Propulsion Type
|
Steam
Turbine; (4) (Westinghouse) |
Total Shaft Horsepower
|
280,000
shp |
Speed
|
30+
knots |
Crew (typ.)
|
Officers:
540; Enlisted: 4818 |
|
|
NIMITZ Class
Specifications
|
Overall Length
|
1115'
- 0" |
Waterline Length
|
1040'
- 0" |
Extreme Beam
|
257'
- 0" |
Waterline Beam
|
134'
- 0" |
Max. Navigational Draft
|
40'
- 0" |
Draft, Keel
|
Not
available |
Draft Limit
|
41'
- 0" |
Light Displacement
|
78,280
tons |
Full Displacement
|
101,196
tons |
Structural Composition
|
Hull:
Steel; Superstructure: Steel |
Number of Propellers
|
4 |
Propulsion Type
|
(4)
General Electric Steam Turbines powered by
(2) Westinghouse A4W Nuclear Reactors |
Total Shaft Horsepower
|
280,000
shp |
Speed
|
30+
knots |
Crew (typ.)
|
Officers:
558; Enlisted: 5454 |
|
|
|
