CLASS SPECIFIC INFORMATION
ARLEIGH
BURKE Class Specifications
Flight
1 / Flight 2 |
Overall Length
|
505'
- 0" |
Waterline Length
|
466'
- 0" |
Extreme Beam
|
66'
- 0" |
Waterline Beam
|
59'
- 0" |
Max. Navigational Draft
|
31'
- 0" |
Draft, Keel
|
Not
available |
Draft Limit
|
22'
- 0" |
Light Displacement
|
6,691
tons |
Full Displacement
|
8,803
tons |
Structural Composition
|
Hull:
Steel; Superstructure: Steel; Mast: Aluminum |
Number of Propellers
|
2
- CRP (Controllable Reversible Pitch) |
Propulsion Type
|
Gas
Turbine; (4) General Electric LM2500 |
Total Shaft Horsepower
|
100,000
shp |
Speed
|
31+
knots |
Crew (typ.)
|
Officers:
26; Enlisted: 315 |
Aircraft
|
None;
helo landing capable, no support |
Approx. Unit Cost
|
Unavailable |
|
|
ARLEIGH
BURKE Class Specifications
Flight
2A |
Overall Length
|
511'
- 0" |
Waterline Length
|
471'
- 0" |
Extreme Beam
|
66'
- 0" |
Waterline Beam
|
59'
- 0" |
Max. Navigational Draft
|
33'
- 0" |
Draft, Keel
|
Not
available |
Draft Limit
|
24'
- 0" |
Light Displacement
|
6,600
tons |
Full Displacement
|
9,157
tons |
Structural Composition
|
Hull:
Steel; Superstructure: Steel; Mast: Aluminum |
Number of Propellers
|
2
- CRP (Controllable Reversible Pitch) |
Propulsion Type
|
Gas
Turbine; (4) General Electric LM2500 |
Total Shaft Horsepower
|
100,000
shp |
Speed
|
31+
knots |
Crew (typ.)
|
Officers:
32; Enlisted: 348 |
Aircraft
|
(2)
SH-60 Sea Hawk (LAMPS III) |
Approx. Unit Cost
|
Unavailable |
|
|
|
